Denon AVC-X4700H

Denon

A class of it’s own, with Auro-3D, premium build-quality, and custom Denon audio technologies for 9 amplifiers to deliver outstanding surround sound
and music experience.

Key Features:

  • High-performance discrete 9-channel amplifier
  • Full 8K/60Hz and 4K/120Hz support
  • Enjoy your favourite 3D audio formats
  • Enhanced Audio Return Channel (eARC) HDMI support
  • The latest in video compatibility
  • The latest in gaming experiences
  • New DSP for more processing power
  • Works with your favourite voice services
  • Wireless streaming from the most popular music services
  • HEOS® Built-in wireless multi-room music streaming technology

$3,499

9.2 Ch. 200W 8K AV Amplifier with HEOS® Built-in

Discover a new world of home entertainment with the new Denon AVC-X4700H. Nine discrete, identical amplifiers rated at 200W each, and 11.2 channel processing capability with two ADI Griffing Lite DSPs will let your home cinema shine in breathtaking Dolby Atmos, DTS:X, IMAX Enhanced and Auro-3D immersive surround sound. The AVC-X4700H supports the latest HDMI video technologies such as 8K/60Hz and 4K/120Hz** pass-through, Dolby Vision, HDR10, HDR10+, Dynamic HDR, HLG, as well as 8K upscaling and HDCP 2.3 support on all HDMI inputs (8 in/3 out).

Stream popular music services like Spotify, TuneIn Internet Radio, Amazon Music HD, TIDAL and more wirelessly via Bluetooth, Apple AirPlay 2 and Wi-Fi with HEOS Built-in. Enjoy your MP3 collection and even Hi-Res audio formats (WAV, FLAC, ALAC and DSD 2.8/5.6 MHz files) via USB or Network. The Denon AVC-X4700H works with Amazon Alexa, Google Assistant and Apple Siri for effortless voice control.

By visually guiding you through each step in the setup process, the award-winning Denon Setup Assistant ensures you get set up right the first time. Every home theatre is different, that’s why Denon uses the premium Audyssey MultEQ XT32 room calibration technology from Audyssey that automatically measures and optimizes your AV amplifier to provide a truly immersive 3D audio experience custom-tailored to your unique listening environment.

High-performance discrete 9-channel amplifier: Delivers a dynamic 200W per channel to provide a trusted, precise and powerful Denon sound experience.

Full 8K/60Hz and 4K/120Hz** support: With the latest HDMI support, enjoy 8K quality video from your 8K source devices. Supporting one 8K input and two 8K outputs allows for 8K/60Hz and 4K/120Hz** pass-through. 8K upscaling is available on all 8 HDMI inputs.

The latest in HDMI support: With 8 advanced HDMI inputs with full HDCP 2.3 support and 3 HDMI outputs, connect to all your favourite media devices and output up to 3 monitor displays so you can enjoy from any room.

Enjoy your favourite immersive 3D audio: Enjoy immersive, 3D audio from sources like Dolby Atmos,

Dolby Atmos Height Virtualization, DTS: X, DTS Virtual:X and Auro-3D.

IMAX Enhanced Technology: Delivers a true IMAX theatre experience at home.

Enhanced Audio Return Channel (eARC) HDMI support: Through the main HDMI output, connect your TV with eARC HDMI support to allow uncompressed and object-based audio formats like Dolby Atmos and DTS:X directly from your smart TV app to your AV amplifier

Weight 13700 g
Dimensions 485 × 538 × 261 mm
Brand

Multichannel Surround

DTS HD Master / DTS:X Yes / Yes
DTS Neo:X / DTS Neural:X No / Yes
DTS Virtual:X Yes
Dolby TrueHD / Dolby Atmos Yes / Yes
Dolby ProLogic II / Dolby Surround No / Yes
Auro 3D Yes
Multichannel Stereo Yes
Max Number of Processing (Preamp) Channels 11.2
IMAX Enhanced Yes

Sound Enhancements

Discrete Power Amplifier 9
D.D.S.C. HD Digital Yes (32 bit)
Pure Direct Yes
High Grade Audio Components Yes
Clock Jitter Reducer Yes
Alpha Processing AL32 Processing Multichannel
Denon Link HD Yes
Audyssey MultEQ XT32
Audyssey Dynamic EQ / Dynamic Volume Yes / Yes
Audyssey LFC Yes
Audyssey APP Support Yes
Compressed Audio Restorer Yes

Network

HEOS Multiroom and Streaming Yes
Lossy Formats: MP3 / WMA / AAC Yes / Yes / Yes
Lossless Formats: FLAC / ALAC / WAV Yes / Yes / Yes
DSD Audio Streaming up to DSD5.6
FLAC HD 192/24 Yes
WAV 192/24 Yes
ALAC 192/24 Yes
Gapless playback Yes (FLAC, WAV, ALAC, DSD)
AirPlay Audio Streaming Yes
AirPlay 2 Yes
Internet Radio TuneIn
Spotify Connect* / Tidal* / Deezer* / others * Yes / Yes / Yes / Yes
Compatible with Remote APP for Smart Phones Android / iOS
Compatible with Remote APP for Tablets Android / iOS/Amazon Kindle
Ethernet Ports Yes
Wi-Fi Yes
Bluetooth Yes

HDMI

HDMI Inputs: Back / Front 7 / 1
HDCP 2.2 support Yes
HDCP2.3 support Yes
HDMI Outputs: Main / Zone 2 / 1
HDMI max Resolution (8k / 4k) 8k/60 – 4k/120**
Video Conversion Analog -> HDMI Yes
Analog to HDMI Scaling 480i/576i up to 8K 60/50
HDMI to HDMI Scaling up to 8K 60/50
GUI Overlay on HDMI Yes
HDMI: 8K / 4K / CEC / eARC Yes / Yes / Yes / Yes
HDMI: 3D / 4K / CEC / ARC Yes / Yes / Yes / Yes
HDMI: Dolby Vision / HDR 10+ / Dynamic HDR / HLG Yes / Yes / Yes / Yes
Enhanced ARC Yes
HDMI: ALLM / QMS / QFT / VRR Yes / Yes / Yes / Yes
HLG / Dolby Vision Yes / Yes
4K Signal Pass-through / Scaling / GUI Overlay Yes / Yes / Yes
HDMI pass-though in standby mode Yes
Picture Adjust / Noise Reduction Yes / Yes
CEC Yes
DSD Audio Capability Yes
Audio Return Channel Yes
Auto LipSync Yes

Multi-room CI

HEOS Multiroom integrated Yes
TV Sound grouping Yes
Multi-Room Zones 3
Zone Audio Source: HDMI / Opt, Coax / Network, USB / Analog Yes (2ch) / Yes (2ch) / Yes / Yes
Zone Audio Output: Speaker / Preout Yes / Yes
Zone HDMI Output from HDMI Source Yes
Webbrowser User Interface Yes
Smart Remote Management Yes
IP Control / RS232 Control / Web Control / App Control Yes / Yes / Yes / Yes
Remote In / Out Yes / Yes
DC Trigger Output 2

Others

Voice Control – Works with Amazon Alexa Yes
Auto Speaker Setup by Microphone Audyssey MultEQ XT32
FL Display 2 lines
Graphic User Interface – GUI Advanced
ISF Certification Yes
GUI Languages 9
Setup Assistant Yes
Quick Select Plus / Quick Select Yes / No
Firmware Update by: Network / USB Yes / Yes
Variable Cross Over Yes
Optimized Bass Redirection Yes
Bass Sync Yes
ECO Mode Yes
Auto Power Off Yes
Sleep Timer Yes

Inputs Outputs

Composite In / Out 3 / 2
Component In / Out 2 / 1
HDMI In / Out 7+1 / 3
Multi-room Video Out: Video / HDMI Yes / Yes
Analogue In/out 5 / No
Phono (MM) In Yes
Digital In: Optical / Coaxial 2 / 2
Multi-room Out: Analog / Digital 2 / No
Multichannel Preout Yes (11.2)
Subwoofer Out 2 (independent)
Speaker Terminal: Gold Plated Screw / Regular Screw No / Yes
Number of Speaker Terminals 11
Speaker A/B / Bi-amp Drive / Multi-Room Speaker assignable
Speaker A / B assignable
Bi-amp Drive assignable
Multi-Room Speaker Terminal assignable
Front Inputs: Audio / Composite / Digital (Opt) / HDMI / USB No / No / No / Yes / Yes
USB Audio / Made for iPod / Made for iPhone Yes / AirPlay / AirPlay
FM Tuner with RDS Yes

Specifications

Number of Power Amps 9
Power Output (8 ohm, 20 Hz – 20 kHz, 0.08% 2ch Drive) 125 W
Power Output (6 ohm, 1 kHz, 0.7% 2ch Drive) 165 W
Power Output (6 ohm, 1 kHz, 1% 1ch Drive) 200 W

General

Available colours: Black / Premium Silver Yes / Yes
Metal Front Panel Yes
System Remote Control RC-1219
Pre-programmed / Learnable / LCD Display Yes / No / No
Power Consumption in W 710
Power Consumption No-Sound (ECO On / Off) in W 65 W / 110 W
Standby Consumption in W 0.1
CEC Standby Consumption in W 0.5
Network Control On Consumption in W 3.7
Maximum Dimensions
Antenna: Horizontal: (W x D x H) in mm
Antenna: Vertical: (W x D x H) in mm
W/O Antenna: (W x D x H) in mm
434 x 389 x 167
( 434 x 389 x 236 )
【 434 x 379x 167 】
Weight in kg 13.7
