Zektor Palladia 8×8 Audio Matrix

VIDEO FEATURES FOR PALLADIA® SERIES

• Supports mandatory 3D formats as per HDMI 1.4a
• HDCP 1.1compliant
• Full HDMI® matrix switching between multiple sources and displays any 8 sources to any 8 displays
• Frequency bandwidth: 2.25Gbps (single link)
• Supported resolutions up to 12 bit deep color at 1080p/60Hz maximum
• On Screen Display (OSD) information for each output
• Extensive interoperability testing
• Reliable key management for low latency switching
• Local HDMI® or HDBaseT® output on the V2 version

PALLADIA® II

• HDMI® over HDBaseT®
• Transmit HDMI 1.4a
• Bi-directional IR, bi-directional RS232
• 10/100 Ethernet Gateway
• Up to 328’ over a single CAT5e/6 with rock solid reliability

PALLADIA® DSP AUDIO PREAMP

• HDMI® Audio Extraction to Stereo L/R or S/PDIF Output
• All pre-amp audio features to include volume, bass, treble, and 5-band EQ per zone
• Analog to digital / digital to analog conversion
• Input/output gain control
• Doorbell feature – output chime to any zone
• And much, much more

CONTROL

• IR, RS-232 and TCP/IP
• Driver support for all major controller libraries such as Control4, Crestron, Elan, RTI, Savant and URC

POWER, RACK AND HARDWARE INFORMATION

• IR Extender Output (3.5mm)
• 3U Rackmount Palladia® 8×8 (no HDBaseT TX)
• 5U Rackmount Palladia® II 8×8
• 8U Rackmount Palladia® II 16×16
• IEC power connection
• Auto detecting power supply: 240V DC/6.25A 110V / 240V
• Palladia® dimensions: 19” (w) x 15.16” (d) x 7” (h)
• Palladia® II dimensions: 19” (w) x 15.16” (d) x 10.5 ” (h)
• Weight: 19.8 Lbs Clarity HD® Elite / 23.0 Lbs Clarity Elite HD® V2
