Denon AVC-X3700H

Denon



Key Features:

  • 4K TV’s, upgraded: Get the most out of your 4K TV until you upgrade to 8K.
  • 9-channels of entertainment: Drive your entire home theatre system with 9 channels of power.
  • Latest HDMI and eARC: Enjoy your favourite movies, shows, and games with the best picture and audio quality available.
  • Full 3D audio support: Immerse yourself in 3D audio and enjoy your entertainment in whatever speaker configuration you’d like.

$2,699

9.2ch 8K AV Amplifier with 3D Audio w/ HEOS

Denon AVC-X3700H 9.2 channel 8K AV amplifier with 180W per channel that fully supports 3D audio formats like Dolby Atmos®, Dolby Atmos Height Virtualization Technology, DTS:X®, DTS Virtual:X™ and IMAX® Enhanced, as well as the latest HDMI specifications such as 8K/60Hz, 4K/120Hz pass-through and upscaling, VRR, ALLM, Dynamic HDR, HDR10+ and eARC support.

Full 3D Audio Support

Immerse yourself in 3D audio with Dolby Atmos, Dolby Atmos Height Virtualization Technology, DTS:X, DTS Virtual: XTM and IMAX Enhanced. Set up a 5.1.4 or  7.1.2 Dolby Atmos surround system using the nine channels of amplification built-in to the AVC-X3700H.

Powerful 9-Channel Amplifier

Featuring discrete high-current amplifiers on all channels, the AVC-X3700H delivers high-power performance at 180W per channel to ensure a powerful and precise entertainment experience, every time.

Ultimate Home Theatre Experience – 8K Ready

The AVC-X3700H delivers the ultimate home theatre experience with 8K/60Hz pass-through, 4K/120Hz pass-through, and support for the latest HDMI specifications. The new AVC-X3700H lets you build the best 4K home theatre and make you 8K ready.





Weight 12500 g
Dimensions 389 × 434 × 167 mm
Brand

Specifications

Number of Power Amps 9
Power Output (8 ohm, 20 Hz – 20 kHz, 0.08% 2ch Drive) 105 W
Power Output (8 ohm, 20 Hz – 20 kHz, 0.05% 2ch Drive) No
Power Output (6 ohm, 1 kHz, 0.7% 2ch Drive) 135 W
Power Output (6 ohm, 1 kHz, 1% 1ch Drive) 180 W

General

Available colors: Black / Premium Silver Yes / No
Metal Front Panel No
System Remote Control RC-1239
Pre-programmed / Learnable / LCD Display No / No / No
Power Consumption in W 660
Power Consumption No-Sound (ECO On / Off) in W 45 W / 80 W
Standby Consumption in W 0.1
CEC Standby Consumption in W 0.5
Network Control On Consumption in W 3.7
Maximum Dimensions
Antenna: Horizontal: (W x D x H) in mm
Antenna: Vertical: (W x D x H) in mm
W/O Antenna: (W x D x H) in mm
434 x 389 x 167
( 434 x 389 x 236 )
【 434 x 379x 167 】
Weight in kg 12.5
Carton Maximum Dimensions (W x D x H) in mm 519 x 478 x 242
Carton Weight (inc. product) in kg 15.1

Inputs / Outputs

Composite In / Out 2 / 1
Component In / Out 2 / 1
HDMI In / Out 6 / 2
Multi-room Video Out: Video / HDMI No / No
Analogue In/out 4 / No
Phono (MM) In Yes
Digital In: Optical / Coaxial 2 / 0
Multi-room Out: Analog / Digital 1 / No
Multichannel Preout Yes (0.2)
Subwoofer Out 2
7.1 Multichannel Input No
Speaker Terminal: Gold Plated Screw / Regular Screw No / Yes
Number of Speaker Terminals 7
Speaker A / B assignable
Bi-amp Drive assignable
Multi-Room Speaker Terminal assignable
Front Inputs: Audio / Composite / Digital (Opt) / HDMI / USB No / No / No / No / Yes
USB Audio / Made for iPod / Made for iPhone Yes / AirPlay / AirPlay
FM Tuner with RDS Yes

Others

Voice Control – Works with Amazon Alexa Yes
Voice Control – Google Assist / Apple Siri Yes / Yes
Voice Control – Microphone built-in No
Auto Speaker Setup by Microphone Audyssey MultEQ XT
FL Display 1 line
Graphic User Interface – GUI Advanced
ISF Certification Yes
GUI Languages 9
Setup Assistant Yes
Quick Select Plus / Quick Select Yes / No
Firmware Update by: Network / USB Yes / Yes
Variable Cross Over Yes
Optimized Bass Redirection Yes
Bass Sync No
ECO Mode Yes
Auto Power Off Yes
Sleep Timer Yes

Multi-room CI

HEOS Multiroom integrated Yes
TV Sound grouping Yes
Multi-Room Zones 2
Main room multichanel audio – Zone stereo downmix Yes
Zone Audio Source: HDMI / Opt, Coax / Network, USB / Analog Yes (2ch) / Yes (2ch) / Yes / Yes
Zone Audio Output: Speaker / Preout Yes / Yes
Zone HDMI Output from HDMI Source No
Webbrowser Setup Yes
IP Control / RS232 Control / Web Control / App Control Yes / No / Yes / Yes
Remote In / Out No / No
DC Trigger Output No

HDMI

HDMI Inputs: Back / Front 6 / 0
HDCP2.3 support Yes
HDMI Outputs: Main / Zone 2 / No
HDMI max Resolution (8k / 4k) 8k/60 – 4k/120**
Video Conversion Analog -> HDMI No
HDMI to HDMI Scaling up to 8K 60/50
HDMI: 8K / 4K / CEC / eARC Yes / Yes / Yes / Yes
HDMI: Dolby Vision / HDR 10+ / Dynamic HDR / HLG Yes / Yes / Yes / Yes
HDMI: ALLM / QMS / QFT / VRR Yes / Yes / Yes / Yes
HDMI pass-though in standby mode Yes
DSD Audio Capability No

Network

HEOS Multiroom and Streaming Yes
Lossy Formats: MP3 / WMA / AAC Yes / Yes / Yes
Lossless Formats: FLAC / ALAC / WAV Yes / Yes / Yes
DSD Audio Streaming up to DSD5.6
FLAC HD 192/24 Yes
WAV 192/24 Yes
ALAC 192/24 Yes
Gapless playback Yes (FLAC, WAV, ALAC, DSD)
AirPlay 2 Yes
Roon Tested Yes
Internet Radio TuneIn
Spotify Connect* / Tidal* / Deezer* / others * Yes / Yes / Yes / Yes
Amazon Prime Music* / Pandora* Yes / Yes
Compatible with Remote APP for Smart Phones Android / iOS
Compatible with Remote APP for Tablets Android / iOS/Amazon Kindle
Ethernet Ports Yes
Wi-Fi Yes
Bluetooth Headphone transmission Yes

Sound Enhancements

Mono Block Power Amp Construction No
Discrete Power Amplifier 7
110th Anniversary Audio Tuning No
Iron diecast feet No
Copper plated transformer base No
Premium speaker terminals No
All black interior No
D.D.S.C. HD Digital No
Pure Direct Yes
High Grade Audio Components Yes
Gold Plated RCA Terminals No
Clock Jitter Reducer No
Alpha Processing No
Audyssey MultEQ XT
Audyssey Dynamic EQ / Dynamic Volume Yes / Yes
Audyssey LFC No
Audyssey APP Support Yes
Speaker Setup Presets 2
Compressed Audio Restorer Yes

Multichannel Surround

DTS HD Master / DTS:X Yes / Yes
DTS:X Pro No
DTS Neo:X / DTS Neural:X No / Yes
DTS Virtual:X Yes
Dolby TrueHD / Dolby Atmos Yes / Yes
Dolby ProLogic II / Dolby Surround No / Yes
Dolby Height Virtualization Yes
Front Wide Speakers: Dolby / DTS No
Auro 3D No
IMAX Enhanced No
MPEG-H No
Multichannel Stereo Yes
Max Number of Processing (Preamp) Channels 7.1
