Wharfedale Diamond 11.4 Floor Standing Speaker


Since 1981, Wharfedale?s famous Diamond speakers have served as the classic entry point to true high-fidelity sound, offering exceptional value for money earning numerous ?product of the year? awards in the UK and around the world.
  • Bass Driver : DUAL 6 inch Woven Kevlar cone
  • Frequency Response (+/-3dB) : 42Hz – 20kHz
  • Nominal Impedance : 8 Ohms Compatible


  • Now, with the all-new Diamond 11 Series, Wharfedale once again raised the bar for affordable, high-performance loudspeakers.
  • The latest generation of Diamond speakers includes design elements never previously seen at such affordable price points.
  • At the start of the design process, Wharfedale?s engineers went back to basics in order to create a loudspeaker system that would once again revolutionise this sector of the hi-fi market and bring high-end performance ? and style ? within reach of most music lovers, not just the wealthy few.
  • High-frequency performance has been similarly enhanced with a newly evolved tweeter design.
  • Again, an over-sized ceramic magnet system is used, with a copper cap for flux control.
  • And, here, the pole piece is vented through to a specially shaped rear chamber.
  • This provides a low resonant frequency, ensuring excellent linearity throughout the operating system and allowing the textile dome to contribute to a lucid midrange performance in addition to precise high-frequency detailing.


  • Bass and midrange driver baskets with a network of ribs for added strength, improving among other things transient impact
  • Massive magnet designs improving sensitivity and control of cone movement
  • Specially shaped single-forged pole piece with copper cap controls the magnetic flux and reducing low distortion through the critical midrange area
  • Progressive suspension featuring lightweight foamed surround for an extended midrange response
  • super-long-throw voice coil motor system to achieve unparalleled linearity and accuracy
  • Woven Kevlar cones
SKU: Diamond 11.4 Categories: ,
Weight 24000 g
Dimensions 320 × 225 × 985 mm

  • Description : 3 Way floor standing speaker
  • Enclosure Type : Rectilinear Bass Reflex (slot loaded)
  • Bass Driver : DUAL 6 inch Woven Kevlar cone
  • Midrange Driver : 4 inch Woven Kevlar cone
  • Tweeter : 1 inch Textile dome
  • Frequency Response (+/-3dB) : 42Hz – 20kHz
  • Sensitivity (2.83V@1m) : 91dB
  • Recommended Amplifier Power : 25W-175W
  • Nominal Impedance : 8 Ohms Compatible
  • Dimensions (H x W x D) in mm : 985 x 225 x 320
  • Weight : 24kg each
  • Stocked Colours : Blackwood, Rosewood, Walnut, White Sandex
