Origin Acoustics D83 In-Ceiling Speaker

Origin Acoustics

In-Ceiling Speaker Featuring An 8-Inch IMG Woofer, pivoting aluminum dome tweeter, and Tool-less Installation
  • X-Wave Woofer Surround
  • Frequency Response : 38Hz-20kHz
  • Cutout Diameter: 8.75″ (222mm)

Please Call to Check Availability

In-Ceiling Speaker Featuring An 8-Inch IMG Woofer, pivoting aluminum dome tweeter and Tool-less Installation

Higher performance demands a certain set of established criteria. Reproducing music and movie soundtracks means moving a lot of air. The D83 is an impressive example of how this can be done with an incredible bang for the buck. Perfect for music throughout the home when music quality is a must.

Feature

Hand Selected Drivers

  • Choosing the right drivers is part of the blend of art and technology that creates Origin Acoustics? signature sound.
  • The 8-inch woofer cone in the D83 is made of injection-moulded graphite which offers low mass while consistently holding the driver?s shape.
  • The aluminum dome tweeter pivots up to 20-degrees allowing the installer to direct the critical high frequencies toward the listening area.

X-Wave Woofer Surround

  • While in motion, frequencies between 700-1,400 Hz typically run up the cone of a woofer and are reflected back and forth from the center of the driver.
  • This creates unwanted harmonic distortion. The X-Wave surround found in Origin woofers absorbs these frequencies reducing distortion and maintaining driver stability.
  • This design also maximizes cone area by reducing the width of the surround.

Progressive Suspension

  • As the driver travels to the limits of its excursion, the suspension, made up of the spider and the surround, becomes more rigid, exerting more control on the movement of the cone.
  • The result is increased, clean power output throughout the driver?s frequency range.

Compression Molded Woofer Baskets

  • Utilizing the latest techniques and materials in plastic fabrication, Origin is able to create basket designs with superior stability and acoustic neutrality.
  • These baskets combine with the driver suspension to increase linearity and improve overall performance.

Tool-Less Installation

  • It is important when installing a loudspeaker in the ceiling that it be stable and secure, restricting the vibration of the assembly and limiting the transfer of energy into the wall.
  • The revolutionary Tool-Less Installation (Patent #9591390) spreads the weight of the speaker over a larger area than typical mounting systems accomplishing this result with minimal effort.
  • Spring-loaded clips also create more uniform pressure against the drywall eliminating any warping or distortion of the speaker baffle.

Magnetic Grille

  • A paintable, perforated grille with a micro bezel covers the entire speaker assembly and leaves a discreet finished appearance. Its magnetic attachment makes removing or replacing the grille fast and easy.

Let it Sink in

  • With an IPX6 rating, the entire Director Collection is at the top of the class. This rating ensures that this high-performance is safe from the corrosion and internal damage commonly posed by exposure to ocean water and rainstorms–backed by a lifetime warranty.
SKU: D83 Categories: ,
Brand

Model NumberD83Part NumberSCD83000Tweeter DomeAluminumTweeter Diameter1″ (25mm)Woofer ConeIMGWoofer Diameter8″ (203mm)Frequency Response38Hz-20kHzRecommended Amplifier Power50 watts – 125 wattsSensitivity91dB +/- 3dBDepth4.13″ (105mm)Diameter9.61″ (244mm)Cutout Diameter8.75″ (222mm)Speaker SeriesDirectorSpeaker ShapeRoundSpeaker Size8″Nominal Impedance6 ohm minimumMounting Depth4.13″ (105mm)
