Marantz PM7000N




Key Features:

  • 2 x 60W output RMS / 8 ohms
  • Proprietary HDAM-SA3 circuits
  • Built-in HEOS Wireless Multi-Room
  • Works With: Alexa / Google / Siri
  • Wi-Fi, AirPlay 2, Bluetooth & USB
  • Supports DSD 2.8/5.6 & 24/192
  • Phono, optical, coaxial inputs
  • Shielded digital/network circuits

$2,400

60W INTEGRATED STEREO AMPLIFIER WITH HEOSยฎ BUILT-IN

Discover the PM7000N, the first Marantz Current Feedback integrated Hi-Fi amplifier with HEOS Built-in technology. The ideal choice for audio connoisseurs, the PM7000N includes high-grade audio components, Marantz own HDAMs, a toroidal transformer and a high-speed instantaneous current power supply.

Stream your favourite music and enjoy high-resolution digital audio files up to 192kHz/24bit or DSD5.6. Switch to the high quality Phono MM input to listen to your beloved vinyls as never before. The digital inputs support PCM audio, and decode – beside MP3 – lossless digital files like ALAC, FLAC and WAV up to 24-bit/192-kHz for high-resolution listening.

USB-A and HEOS Built-in additionally support DSD 2.8MHz and 5.6MHz playback. Stream your favourite music wirelessly via AirPlay2 and Bluetooth, and control the amplifier via the HEOS app or with leading voice agents Apple Siri, Google Assistant and Amazon Alexa where supported.

Highlights and Benefits:

  • Power to suit your audio preference: 2 channel fully discrete current feedback integrated Hi-Fi amplifier; 60W per channel (8-ohm, 20Hz โ€“ 20kHz)
  • Marantz proprietary HDAM-SA3 circuit: Wide dynamic range and famous Marantz soundstage
  • Shielded toroidal transformer: Delivering high level of clean power for pure amplification without distortion
  • Built-in Bluetooth and Wi-Fi with 2.4GHz/5GHz dual band support: Improved network stability even in Wi-Fi crowded homes
  • HEOS Built-in wireless music streaming: Play nearly unlimited music from your favourite streaming services like Spotify Free and Premium, Amazon Music, Deezer, TuneIn Internet Radio and more with the comfortable HEOS app
  • Wide range of connectivity: Four analogue inputs, one analogue output, one coaxial input, two optical digital inputs and one USB-A for high resolution audio files
  • High-performance, high-resolution audio playback: Supports high-resolution audio ALAC, FLAC and WAV lossless files up to 24-bit/192-kHz โ€” plus, DSD 2.8MHz and 5.6MHz tracks for high-resolution listening supported by a high performance audio DAC AK4490
  • Play vinyl with exceptional clarity: Integrated phono input with newly design FET input stage to improve signal purity and improve sound
  • Fully shielded digital and network section with the option to deactivate: Minimises the risk of interference by digital section to achieve highest audio performance and a pure analogue experience
  • Premium Marantz SPKT-1+ speaker terminals: Improved connection to speakers for high quality playback
  • Speak your commands: Supports Amazon Alexa, Google Assistant and Apple Siri voice agents for seamless voice control
  • Works with your TV remote: Program the PM7000N to work with your TV remote and easily adjust volume up, volume down, mute and source selection

Power To Suit Your Audio Preference
2ch fully discrete current feedback integrated Hi-Fi amplifier; 60W per channel (8-ohm, 20Hz โ€“ 20kHz)

Wide Range Of Connectivity
Four analog inputs, one analog output, one coaxial input, two optical digital inputs and one USB-A for high resolution audio files

Advanced Marantz Sound
Wider dynamic range with lower distortion for the output stage from Marantz’s latest HDAM-FA3 technology

Flexibility For All Configurations
Tone control to tune sound to your exact specifications and dedicated subwoofer output for evenly dispersed bass, no audible peaks or dips

Modern Integrated Amplifier
The PM7000N is the first fully discrete, current feedback integrated Hi-Fi amplifier with HEOS Built-in technology from Marantz. It is the ideal choice for audiophiles that require Marantz Musical sound with flexible operation and access to digital streaming music. The amplifier delivers a powerful 2x 60W into 8 ohm or 2 x 80W into 4 ohm (20Hz โ€“ 20kHz).

Fully Discrete Current Feedback Power Amplifier
Current Feedback amplification, a renowned Marantz-proprietary circuit technology, is thoughtfully designed to match the requirements of Super Audio hi-res music for wide-bandwidth, high-speed reproduction. The impedance at the Current Feedback point is limited, generating a very low phase shift. Marantz Current Feedback amplifiers reduce the need for phase compensation by minimizing Negative Feedback (NFB).

Marantz HDAM-S3 Technology
Marantz developed its own discrete circuit boards called Hyper-Dynamic Amplifier Modules, or HDAMs, to replace the chip-based amps used elsewhere. Using discrete surface mount components with short mirror-image left and right signal paths, HDAMs outperform the regular integrated Op-amps dramatically in Slew Rate and noise level. The result is much more dynamic, accurate and detailed sound. Over the years, Marantz developed different HDAMs to fit the particular requirements of each player and amplifier. The PM7000N uses the high-grade SA3 version.

The Most Musical Sound
Engineered and extensively tuned by a team drawing on more than 65 years of Hi-Fi expertise, the PM7000N provides exceptional performance for your audio collection. Whether digital or analog, enjoy the most musical sound from any source.



Weight 10800 g
Dimensions 379 × 440 × 125 mm
Brand

Color

Black, Silver/Gold

Features

Channels 2
Current Feedback Topology Yes
Phono EQ: OP amp + FET input stage
HDAM version HDAM-SA3, SA2
Power Transformer Toroidal
High Grade Audio Components Yes
Customised Components Yes
Symmetric PCB Layout Yes
Aluminium extrusion heat sink Yes
Tone Control: Bass / Treble / Balance Yes / Yes
Source Direct Yes
Pure Modes 3

Inputs/Outputs

Audio Inputs 4
Phono Input: MM Yes
Digital In: Optical / Coaxial 2 / 1
USB-A 1 (rear)
Recorder out Yes
Pre-out Subwoofer
Power Amp Direct IN No
Gold Plated Cinch Yes
Speaker A / B No
Speaker Terminals Marantz SPKT-1+
Number of terminals 1 pair
Remote Control Bus in / out Yes
Headphone Out Yes (Front)

Network

HEOS Multi-room and Streaming / Network Audio Streaming Yes / Yes
Lossy formats: MP3 / WMA / AAC Yes / Yes / Yes
Lossless formats: FLAC / ALAC / WAV Yes / Yes / Yes
Lossless formats: FLAC HD 192/24 / WAV 192/24 / ALAC 192/24 Yes / Yes / Yes
DSD Audio Streaming up to DSD5.6
Gapless Playback Yes (FLAC, WAV ,ALAC ,DSD)
AirPlay 2 Audio Streaming Yes
Internet radio Yes (TuneIn)
Spotify connect / Deezer / TIDAL / Napster / Pandora / SiriusXM Yes / Yes / Yes / Yes / Yes / Yes
Support for voice control: Alexa/Google assistant / Siri Yes / Yes / Yes
Compatible with Remote APP for Smart Phones HEOS
Ethernet / Wi-Fi Yes / Yes (dual antenna/ dual band)
Bluetooth Yes

Specifications

Power Output (8 / 4 Ohm RMS) 60 W / 80 W
Frequency response 5 Hz โ€“ 100 kHz ยฑ3 dB
Total Harmonic Distortion 0.02%
Damping Factor 100 and over
Input Sensitivity: MM 2.0 mV / 47 kฮฉ/kohms
Signal to Noise Ratio: MM 87 dB (5 mV input, 1 W output)
Input Sensitivity: High level 220 mV/18 kฮฉ
Signal to Noise Ratio: High level 115 dB (2 V input, rated output)

Others

FL Display 3 line OLED
GUI Languages English / French / Spanish
Setup Assistant Yes
Firmware Update by Network / USB Yes
Variable Cross Over Yes (40/60/80/100/120Hz)
Shield Case for Digital Circuit Yes
IR Learning for TV remote Yes
Auto Power On / Off Optical In 1 / Optical In 2 / Coaxial In (Default: OFF)
Sleep / Timer Yes

General

Available Colors SG / BK
Metal Front Panel Yes
Power Consumption 220W
Network Standby Consumption in W 4.7
Standby Consumption 0.4W
Detachable Power Cable Yes
Remote Control Yes
System Remote Function Yes
Maximum Dimensions (W x D x H) 440 x 125 x 379 mm *excluding antennas
Weight 10.8kg
