Blustream UEX3D-WP-US

Blustream

The Blustream UEX3D-WP-US is a sleek, dual Decora® wall plate USB 3.2 Gen1 HDBaseT™ extender that delivers high-speed, long-distance USB connectivity. It supports up to four USB devices (2 x USB-A, 2 x USB-C) over a single CAT6A cable, extending up to 100 meters with a combined data transfer rate of up to 5Gbps. Compatible with USB 2.0 and 1.1 devices, it features bi-directional Power over Cable (PoC) and plug-and-play installation—no drivers required. Ideal for extending USB conferencing cameras, video capture devices, and more in modern AV setups.

$699

Wishlist
Compare
Share

The UEX3D-WP-US is a USB Device solution utilises HDBaseT™ technology to allow for remote connectivity to a USB 3.2 Gen1 Host at distances of up to 100m over a single CAT6A cable in a dual Decora® wall plate format. The UEX3D-WP-US allows for 4 x USB Devices (2 x USB type A, and 2 x USB-C) to be connected to a compatible Blustream USB HDBaseT Receiver (Host) extender with support for a combined transmission data bandwidth of up to 5Gbps.

The UEX3D-WP-US is backwards compatible with USB 2.0 and 1.1 devices, and utilises bi-directional Power over Cable (PoC) to power from either end of the HDBaseT link. The UEX3D-WP-US is ideal for applications requiring extension of USB 3.2 Gen1 conferencing cameras, video capture devices, flash/hard drives, KVM devices, audio devices and other USB 3.2 Gen1 devices.

* Requires compatible Blustream USB 3.2 HDBaseT Host product

SKU: UEX3D-WP-US Category:
Weight 600 g
Dimensions 46 × 89 × 105 mm
Brands

• CAT Connectors: 1 x RJ45 connector
• USB Device Ports: 2 x USB Type C female, 2 x USB Type A female
• Local power input: 1 x 2-Pin Phoenix connector
• Firmware Upgrade: 1 x Micro-USB
• RS-232: 1 x 3-Pin Phoenix connector
• Power Supply: 24V/1.5A DC
• Dimensions (W x H x D): 89mm x 105mm x 46mm (without faceplate) TBC
• Faceplate Dimensions (W x H x D): 120mm x 120mm x 6mm (faceplate) TBC
• Mounting hole spacing: US 83mm CTC
• Backbox Mounting Depth: 40mm (minimum), 47mm (recommended), US double gang junction box
• Shipping Weight: 0.6kg
• Operating Temperature: 32°F to 104°F (-5°C to +55°C)
• Storage Temperature : -4°F to 140°F (-25°C to +70°C)
