Blustream PRO-IN4H Custom Pro 4K – Input Board

Blustream
Availability:

Out of stock


  • Features 4x HDMI inputs which can be independently routed to video output cards
  • Supports up to 4K UHD video (3840 x 2160 @30Hz 4:4:4, 4096 x 2160 @24Hz 4:4:4, and 4K @60Hz 4:2:0)
  • Supports all known HDMI audio formats including Dolby TrueHD, Dolby Atmos, Dolby Digital Plus, and DTS-HD Master Audio transmission
  • Quick-release card module fittings allowing simple population of input and output cards in Custom Pro Matrix Hub
  • HDCP 2.2 compliant

The PRO-IN4H input board offers 4x HDMI sources that can be independently routed to any HDMI/HDBaseT output board and feature quick release card module fittings allowing simple installation into the Custom Pro Matrix hub.

SKU: PRO-IN4H Category:
Brand

Video Input Connectors: 4x HDMI Type A, 19-pin, female

Card Dimensions (W x H x D): 190mm x 22mm x 177mm

Dimensions Including Connections (W x H x D): 190mm x 22mm x 188mm

Shipping Weight: 0.5kg

Operating Temperature: 32°F to 104°F (0°C to 40°C)

Storage Temperature : -4°F to 140°F (-20°C to 60°C)
