- The PRO-IN2H2V input board offers 2x HDMI and 2x VGA sources that can be independently routed to any HDMI/HDBaseT output board and feature quick release card module fittings allowing simple installation into the Custom Pro Matrix hub.
- Features 2x HDMI 2.0 inputs which can be independently routed to video output cards
- Supports HDMI 2.0 18 Gbps specification including HDR
- Supports up to 4K UHD 60Hz 4:4:4
- Supports all known HDMI audio formats including Dolby TrueHD, Atmos, and DTS-HD Master Audio transmission
- Each HDMI input includes an independent fixed level 2ch analog audio breakout allowing connection to a local third party audio solution (supports 2ch PCM)
- Quick-release card module fittings allowing simple population of input and output cards in Custom Pro Matrix Hub
- HDCP 2.2 Support
