Blustream PRO-IN2H2TCS-V2
Experience flawless 4K video and audio switching with the Blustream PRO-IN2H2TCS-V2 — the ultimate 2x HDMI + 2x HDBaseT™ input card for Pro Matrix systems. Designed for high-performance AV distribution, it’s built for speed, clarity, and control.
$1,750
Blustream PRO-IN2H2TCS-V2 is a versatile 4-way input board designed for the Custom Pro modular matrix system, featuring two HDMI 2.0 and two HDBaseT™ inputs that support 4K 60Hz 4:4:4 video, HDR, and HDCP 2.2 compliance. Utilizing CSC technology, it enables signal distribution up to 100 meters at 1080p or 70 meters at 4K when paired with compatible Blustream CSC transmitters. Each input can be independently routed to any HDMI or HDBaseT™ output board, and the HDBaseT™ inputs include IR distribution for source control at connected transmitters. This input board is ideal for professional AV installations requiring flexible and high-quality video distribution.
| Weight | 500 g |
|---|---|
| Dimensions | 150 × 50 × 180 mm |
| Brands |
Video Input Connectors: 2 x HDMI Type A (19-pin, female), 2 x HDBaseT™ RJ45 connectors
Audio Output Connectors: 4 x Analog Left/Right audio (3.5mm stereo jack)
IR Input Ports: 2 x 3.5mm stereo jack
Card Dimensions (W x H x D): 170mm x 22mm x 182mm
Dimensions Including Connections (W x H x D): 190mm x 22mm x 188mm
Operating Temperature: 0°C to 40°C (32°F to 104°F)
Storage Temperature: -20°C to 60°C (-4°F to 140°F)
