Blustream IP500UHD-TZ

Name: Blustream IP500UHD-TZ - Scandalous Performance Unleashed
Brand: Blustream
Price: 2299.00 AUD
Availability: InStock

Experience unparalleled 4K video distribution with the Blustream IP500UHD-TZ SDVoE transceiver. Delivering zero-latency, visually lossless 18Gbps 4K 60Hz 4:4:4 video over 10Gb networks, it supports HDR formats including Dolby Vision and multi-channel audio like Dolby Atmos and DTS:X. Versatile in function, it operates as both transmitter and receiver, featuring PoE+, USB/KVM, IR, RS-232, and Ethernet pass-through. Ideal for matrix setups, video walls, and multiview displays, the IP500UHD-TZ ensures seamless, high-quality AV integration in any professional environment.

$2,299

Wishlist

Compare

The Blustream IP500UHD Transceiver is a SDVoE AV over IP solution that provides the highest-quality, un-compromised 18Gbps 4K with zero latency Audio/Video extension over copper or optical fiber 10Gb Managed Networks.

The IP500UHD-TZ includes support for HDMI 2.0 including distribution of HDR (High Dynamic Range), 10-bit color content, and multi-channel HD audio signals.

The IP500UHD-TZ provides advanced features including PoE+ and transmission of multiple control and data signals alongside audio and video, including IR, RS-232, USB (KVM) and 1Gb Ethernet.

The IP500UHD-TZ is ideal for mission-critical 18Gbps HDMI installations where multiple transceivers can be combined with one or more 10GbE copper / fiber switches to form a distributed video matrix, multi-viewer, or video wall system.

Category: Uncategorized

Weight	1000 g
Dimensions	153 × 191 × 25 mm
Brands	Blustream

• Video input: 1 x HDMI Type A, female
• Video output: 1 x HDMI Type A, female
• Latency: 100 microseconds (0.1ms) with no video compression (<16ms with mild video compression – 10-18Gbps HDMI signals) No latency on HDMI Loop out when in Encoder / Transmitter mode
• Audio input/Output: 1 x 5-pin Phoenix connector
• Ethernet port: 1 x 10GBaseT RJ45 Video network, 1 x SFP+ module video network, 1 x 1Gb LAN RJ45 pass-through
• RS-232 serial port: 1 x 3-pin Phoenix connector
• USB/KVM Port: 1 x USB-Type B (host) , 2x USB-Type A (device)
• IR input: 1 x 3.5mm stereo jack
• IR output: 1 x 3.5mm mono jack
• PoE+ draw: 12.8W (typical), 13.5W (max load)
• Dimensions (WxDxH): 191mm x 153mm x 25mm
• Dimensions Including Connections (WxDxH): 191mm x 158mm x 25mm
• Shipping Weight: 1kg
• Operating Temperature: 32°F to 104°F (0°C to 40°C)
• Storage Temperature : -4°F to 140°F (-20°C to 60°C)
