Blustream HMX44-18G-KIT

Blustream

Blustream HMX44-18G-KIT

4×4 HDBaseT™ ARC Matrix Supporting Uncompressed 4K 60Hz 4:4:4

The Blustream HMX44-18G-KIT Matrix is an industry leading uncompressed, unconverted HDMI 2.0 4K 60Hz 4:4:4 HDCP 2.3/2.2 solution utilising HDBaseT™ 3 technology to deliver HDMI, Bidirectional IR & RS-232, ARC, 1Gb Ethernet, and PoC up to lengths of 100m over a single CAT6A cable.

The HMX44-18G-KIT supports uncompressed distribution of the latest HDR resolutions including HDR10/10+ and Dolby Vision resulting in the ultimate in picture quality for your critical viewing areas.

The Matrix also provides advanced features including simultaneous HDBaseT™/HDMI on output 1, video smart scaling on HDBaseT outputs, and an independent 14×4 audio matrix, and ARC. The Blustream HMX44-18G-KIT includes an in-built web browser interface module for control and configuration of the Matrix, and RS-232, IR and 1Gb Ethernet pass through to enable seamless 3rd party control integration.



$6,999

Blustream HMX44-18G-KIT

4×4 HDBaseT™ ARC Matrix Supporting Uncompressed 4K 60Hz 4:4:4

The Blustream HMX44-18G-KIT Matrix is an industry leading uncompressed, unconverted HDMI 2.0 4K 60Hz 4:4:4 HDCP 2.3/2.2 solution utilising HDBaseT™ 3 technology to deliver HDMI, Bidirectional IR & RS-232, ARC, 1Gb Ethernet, and PoC up to lengths of 100m over a single CAT6A cable.

The Blustream HMX44-18G-KIT supports uncompressed distribution of the latest HDR resolutions including HDR10/10+ and Dolby Vision resulting in the ultimate in picture quality for your critical viewing areas.

The Matrix also provides advanced features including simultaneous HDBaseT™/HDMI on output 1, video smart scaling on HDBaseT outputs, and an independent 14×4 audio matrix, and ARC. The Blustream HMX44-18G-KIT includes an in-built web browser interface module for control and configuration of the Matrix, and RS-232, IR and 1Gb Ethernet pass through to enable seamless 3rd party control integration.

• Advanced uncompressed, unconverted, HDMI over HDBaseT™ technology offering distribution of bit-for-bit 4K HDMI video and audio over a single CAT6A cable
• Features 4 x HDMI inputs which can be independently routed to 4 x HDBaseT™ outputs
• Output 1 features a simultaneous HDMI and HDBaseT™ output
• Supports distribution of uncompressed HDMI2.0 18Gbps specification including 4K 60Hz 4:4:4 UHD video up to 100m*
• Supports distribution of the latest HDR resolutions including HDR10/10+ and Dolby Vision
• 14×4 Audio Matrix independently controllable from video. Audio source inputs include:
– 4 x audio breakout from HDMI source inputs
– 4 x audio breakout from zone outputs
– 4 x audio return from zone outputs*
– 1 x optical and 1x analogue audio input
• Supports all known HDMI audio formats including Dolby TrueHD, Dolby Atmos, Dolby Digital Plus and DTS-HD Master Audio transmission
• Integrated Ethernet switch (LAN Serving) when used with Blustream RX18G receiver (1Gb maximum)
• Web interface module for control and configuration of the Matrix
• Supports bi-directional IR and RS-232 on all HDBaseT™ outputs
• Control via front panel, IR, iOS / Android App, RS-232 and TCP/IP
• Supports PoC (Power over Cable) to power the supplied HDBaseT™ receivers
• Advanced EDID management and HDCP 2.3 compliant
• Supplied with 4 x RX18G HDBaseT™ Receivers

* Transmission distance is subject to video format, cable type and installation environment. It is recommended to use a minimum of CAT6A cabling



**ARC feature supports HDMI ARC or Optical ARC. Compatible with RX18G only

SKU: blustream-hmx4418g-kit Category:
Weight 8700 g
Dimensions 44 × 436 × 360 mm
Brand

Specifications

• Video Input Connectors: 4 x HDMI Type A, 19-pin, female
• Video Output Connectors: 1 x HDMI Type A, 19-pin, female, 4 x HDBaseT™ RJ45 connectors
• Audio Input Connectors: 1 x Analogue audio L/R (3.5mm stereo Jack), 1 x Optical (S/PDIF)
• Audio Output Connectors: 4 x Analogue audio L/R (3.5mm stereo Jack), 4 x Optical (S/PDIF)
• RS-232 Serial Port: 5 x 3-pin phoenix connector
• TCP/IP Control Port: 1 x RJ45, female
• Ethernet Passthrough Port: 1 x RJ45, female
• IR Input Ports: 6 x 3.5mm stereo jack
• IR Output Ports: 5 x 3.5mm mono jack
• Product Upgrade Port: 1 x Micro USB, female
• Rack Mountable: 1U rack height, rack ears included
• Casing Dimensions (W x H x D): 436mm x 360mm x 44mm (without feet)
• Shipping Weight: 8.7kg
• Operating Temperature: 23°F to 131°F (-5°C to +55°C)
• Storage Temperature: -13°F to 158°F (-25°C to +70°C)
• Power Supply: Internal 100-240V AC • HDBaseT Power Output: 24V DC 0.75A per port
