Blustream DA11ABL-WP-EU-V2
DA11ABL-WP-EU-V2 is a Bluetooth and analogue I/O wall plate for Dante® systems—stream, decode, and integrate audio with ease. PoE-powered and perfect for BYOD setups.
$999
DA11ABL-WP-EU-V2 is a sleek, all-in-one Bluetooth and analogue audio wall plate designed to bridge everyday devices with professional Dante® networked audio systems. With support for both input and output, this wall plate converts Bluetooth or unbalanced analogue audio into Dante® digital audio, while simultaneously decoding Dante® streams into unbalanced 2-channel analogue output—making it perfect for BYOD (Bring Your Own Device) environments.
Powered via PoE or 12V, the DA11ABL-WP-EU-V2 also supports AES67 audio transport and features independent I/O paths, offering flexibility for integration into both residential and commercial AV installations. Its magnetic faceplate is compatible with UK and EU backboxes, ensuring a streamlined fit across global install standards.
| Weight | 300 g |
|---|---|
| Dimensions | 85 × 55 × 5 mm |
| Brands |
• Audio Input Connectors: 1 x Analogue Left / Right audio (3.5mm stereo jack)
• Audio Output Connectors: 2 x Analogue RCA (Left / Right)
• Network Connectors: 1 x PoE Dante® Ethernet Connection (RJ45)
• Bluetooth: Bluetooth V5.0 – SBC / MP3 / AAC / APT-X / APTX-LL / APTX-HD, 44.1K-48KHz 16 / 24Bit
• Configuration Switches: 1 x Push button (connect / selection)
• Firmware Upgrade: 1 x Micro-USB UART port
• Module Dimensions (W x H x D): 74mm x 74mm x 50mm (without faceplate)
• Faceplate Dimensions (W x H x D): 85mm x 85mm x 5mm
• Cut Out Dimensions (W x H x D): 52mm x 55mm x 38mm
• Mounting Hole Spacing: UK 60mm CTC, EU 60mm CTC
• Backbox Requirements: UK single gang backbox / EU single gang backbox
• Shipping Weight: 0.3kg
• Operating Temperature: 32°F to 104°F (0°C to 40°C)
• Storage Temperature: – 4°F to 140°F (- 20°C to 60°C)
• Power Supply: Class 1 IEEE 802.3af POE PD or 12V/1A DC, 2-Pin Phoenix connector
